Size: 1/2" ~ 2"(DN15 ~ DN50)
Rating: ANSI 150lb ~ 2500lb(PN16~PN420）
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel
Trim: Per API 600
Operation: Handwheel
Applicable Standard:
Design Standard: API 602, ASME B16.34, BS 5352, DIN3352
Face to Face: ASME B16.10, EN 558, DIN3202
End Flange: ASME B16.5, DIN2533
Buttwelding Ends: ASME B16.25, DIN3239
Socket Welded Ends: ASME B16.11
Threaded Ends: ASME B1.20.1
Inspection and Test: API 598, DIN3230
Design Features:
● Solid or wedge gate
● Full port or reduced port design
● Bolted bonnet, welded bonnet, or pressure sealed bonnet
● End connection：RF, BW, RTJ,SW ,NPT
